Light sources
The suspension system is equipped either with a halogen light source,
a Superlux Eye light source or with a Superlux Eye light source with an
additional, integrated halogen light source (option).
1 Superlux Eye light source
This illumination system comprises a xenon lamp featuring fiber illumination.
The xenon lamp generates light whose spectrum resembles that of natural
daylight. Regardless of the brightness setting, the color temperature of
the light always remains the same. Normal daylight film without any
additional conversion filters can therefore be used for photographic
documentation. Several swing-in filters can be selected to change the light
spectrum.
A second lamp is used as a backup lamp which must be manually swung
into the illumination beam path when the first lamp fails. You have to pull
out the lamp module all the way before being able to swing in the backup
lamp.
2 Halogen light source (option)
This illumination system comprises a light source featuring fiber illumination.
The lamp housing contains a backup lamp which automatically swings
into position when the first lamp fails.
If required, the light source can be equipped with a second lamp housing
so that two separate light sources are available for fiber illumination.
The second light source can be used, for example, for a fiber slit lamp.
3 Superlux Eye - with additional integrated halogen light source (option)
This system comprises a Superlux Eye and a halogen light source suitable
for use in the VISULUX fiber slit lamp, for example.
CAUTION Injury to the patient's eye!
• When using the Superlux Eye light source, only operate the system with
special xenon lamps approved by ZEISS for ophthalmic surgery. If any
lamps other than ZEISS-approved xenon lamps are used, there is the risk
of severe injury to the patient's eye.
