Device overview S88 / OPMI Lumera T
Version 8.0
Page 74 G-30-1682-en
The integrated assistant's microscope comprises the following
components:
18 Clamping screw for locking the tube
within the 12° range of rotation. After adjusting the microscope as
required, secure the tube in its position using the clamping screw.
Firmly tighten the clamping screw by hand.
19 Tube for the assistant
– Invertertube (standard)
20 Knob for setting the interpupillary distance (54 mm to 76 mm)
The correct position has been reached when the two eyepiece images
merge into one.
21 Inverter selection knob
The inverter is fully rotatable and locks into place at both defined positions.
22 Focusing knob
for focusing the assistant's microscope independently of the main surgeon.
23 Manual magnification changer
24 Clamping screw for locking the tilt position
of the integrated assistant's microscope within the 15° tilting range.
After tilting the integrated assistant's microscope as required, secure it in
position using this screw. Firmly tighten the clamping screw by hand.
25 Clamping screw for locking the assistant's microscope in position
After adjusting the assistant's microscope as required, secure it in position
using this screw. Firmly tighten the clamping screw by hand.
