ZKTeco ProCapture-T User Manual

4 ProCapture-T & PRoRF-T User Manual
1.2.4 Card Verification 
Remarks: Card function is optional, only products with a built-in card module are equipped with
card verification function. Please contact our technical support as required.
1. Swipe the card above the card reader (the card must be registered first)
2. Verification succeeds
3. Verification fails
1.3 Initial Interface
When the device is turned on, the initial interface is shown as below:
Date & Time
Alarm Signal
Bell Signal
Time
Network
Connection Signal

ZKTeco ProCapture-T Specifications

General

Type	Intelligent access control reader
Product color	Black
Cards capacity	10000 cards
RFID frequency	0.125 MHz
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
PC connection	RS-485/Wiegand
Supported network protocols	TCP/IP
Viewing angle, horizontal	120 °
Display type	TFT-LCD
Display diagonal	2.4 \
Operating temperature (T-T)	-10 - 50 °C
DC voltage range	12 - 12 V
Power consumption	500 mA
Flash memory	0.256 GB
Internal memory	0.128 GB
Processor frequency	1200 MHz

Weight and Dimensions

Depth	35 mm
Width	87 mm
Height	195.5 mm
