ZKTeco ProCapture-T User Manual

Error! Use the Home tab to apply 标题 1 to the text that you want to appear here.
9
2. The device supports user ID ranged from 1 to 9 digits.
4.2 Setting Access Control
User access control option is to set open door access aimed at everybody, including access group setting,
using time period, duress fingerprint management.
Access group: To allocate users to different access control groups for management. New users belong to
Group 1 in default settings, who can be reallocated to other groups. A valid group number ranges from 1
to 99.
Time Period: Select time rules for the user. Time rules are set under the Access Control menu and a
maximum of 50 time rules are supported. The effective door opening time period of the user is the sum
of the selected time rules.
Duress Fingerprint: User can choose one or more registered fingerprint(s) as Duress Fingerprint. When
that fingerprint is verified, duress alarm will be triggered.
Example: Among those registered fingerprints (6, 7, 8), choose the 8
th
fingerprint as the duress
fingerprint.
4.3 Searching User
Enter user ID on the [All Users] List to search for a user.

ZKTeco ProCapture-T Specifications

General

Type	Intelligent access control reader
Product color	Black
Cards capacity	10000 cards
RFID frequency	0.125 MHz
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
PC connection	RS-485/Wiegand
Supported network protocols	TCP/IP
Viewing angle, horizontal	120 °
Display type	TFT-LCD
Display diagonal	2.4 \
Operating temperature (T-T)	-10 - 50 °C
DC voltage range	12 - 12 V
Power consumption	500 mA
Flash memory	0.256 GB
Internal memory	0.128 GB
Processor frequency	1200 MHz

Weight and Dimensions

Depth	35 mm
Width	87 mm
Height	195.5 mm
