Even parity check bit Failure ID = 1 in binary system Odd parity check bit
16.3 Image Uploading Rule
1. User photo: It is required to create a file named as “photo” under the USB disk file, and put user
photos into the file. The capacity is 3000 images, with each of them not exceeding 15k. The image
name is x.jpg (x is the actual user ID, max. 9 digits). The photo format must be JPG.
2. Advertising image: It is required to create a file named as “advertise” under the USB disk file, and
put advertising images into the file. The capacity is 20 images with each of them not exceeding 30k.
Image name and format are not restricted.
3. Wallpaper: It is required to create a file named as “wallpaper” under the USB disk file, and put
wallpapers into the file. The capacity is 20 images with each of them not exceeding 30k. Image name
and format are not restricted.
Note: When each user photo and attendance photo does not exceed 10k, the device can save a
total number of 10000 user and attendance photos (considering the actual capacity of the device, it is
strongly suggested to upload 5000 user and attendance photos at most).
16.4 Anti-passback Settings
To avoid some persons following users to enter the door without verification, resulting in security
problem, users can enable anti-passback function. The check-in record must match with check-out
record so as to open the door.
This function requires two devices to work together: one is installed inside the door (master device) and
the other one is installed outside the door (slave device). The two devices communicate via Wiegand
signal. The Wiegand format and Output type (User ID / Badge Number) adopted by the master device
and slave device must be consistent.
