each menu for User Defined Role 1 (2 /3). After selection, press back to User Defined Role 1 (2 /3)
editing interface.

ZKTeco ProCapture-T Specifications

General

Type	Intelligent access control reader
Product color	Black
Cards capacity	10000 cards
RFID frequency	0.125 MHz
Fingerprint reader	Yes
Authentication type	Access chip/card, Biometric, Password
PC connection	RS-485/Wiegand
Supported network protocols	TCP/IP
Viewing angle, horizontal	120 °
Display type	TFT-LCD
Display diagonal	2.4 \
Operating temperature (T-T)	-10 - 50 °C
DC voltage range	12 - 12 V
Power consumption	500 mA
Flash memory	0.256 GB
Internal memory	0.128 GB
Processor frequency	1200 MHz

Weight and Dimensions

Depth	35 mm
Width	87 mm
Height	195.5 mm
