ZKTeco SpeedFace-V5L Series User Manual

SpeedFace-V5L Series User Manual
Page | 15 Copyright©2022 ZKTECO CO., LTD. All rights reserved.
 Press the corresponding punch state key to select your current punch state, which is displayed in green.
Please refer to "Shortcut Key Mappings
" for the specific operation method.
Note: The punch state options are off by default and need to select other mode options in the "Punch
States Options" to get the punch state options on the standby screen.

ZKTeco SpeedFace-V5L Series Specifications

General

Face Capacity	50, 000
Card Capacity	50, 000
Display	5-inch Touch Screen
Operating System	Linux
Certifications	CE, FCC
Communication	TCP/IP, Wi-Fi
Power Supply	DC 12V/3A
Operating Temperature	-10°C to 45°C
Operating Humidity	20% to 80%
Standard Functions	Anti-Passback, Tamper Alarm
Access Control Interface	Exit Button, Door Sensor
Face Recognition Speed	< 1s
Face Recognition Distance	0.3m-2m
Processor	1GHz Dual-Core CPU
Camera	2MP Binocular Camera
