114
HINT
This can be set to Mute or from −48.0 to +12.0 dB
■ Adjusting connected equipment levels
(playing test tones)
5. Use and to select the
line output sine wave icon, and
press
to play a test tone.
6. Press to stop test
tone playback.
HINT
•
• While checking the audio level meter of the connected device, make
adjustments to the input gain of that device until the audio signal level is
about −6 dB.
•
• The test tone is a 1kHz sine wave at −6 dBFS.
NOTE
•
• See the manual of the connected device for information about its
operation.
•
• If the automatic gain control function on the other device is on, turn it off.
•
• The test tone is output from both the LINE OUT and HEADPHONE jacks.
•
• Be careful with the volume if you are monitoring the sound with head-
phones, for example.
To Next Page
