92
Changing the phantom power settings
HINT
Phantom power is a function that supplies power to devices that require an
external power supply, including some condenser mics.
The standard power is +48 V, but some devices can operate with lower
voltages.
NOTE
Do not use this function with devices that are not compatible with phan-
tom power. Doing so could damage the device.
The can provide phantom power. The voltage can be set to +24V or +48 V and it can be turned on/off for each input separately.
1. Press .
2. Use and to select
INPUT, and press
.
3. Use and to select Phan-
tom Settings, and press
.
▶ Continue to one of the following procedures.
Setting the voltage ………………………………………………………………… P.93
Disabling phantom power during playback …………………………P.93
Using phantom power …………………………………………………………… P.78
To Next Page
