24
Selecting inputs and adjusting levels
Select which among Inputs 1–6 to use.
Inputs will be recorded on tracks with the same numbers. For example, Input 1 will be recorded on track 1 and Input 2 will be recorded on track 2.
Selecting inputs
1. Turn right for the number of an input to record,
making the track status indicator light.
HINT
Turn left until it clicks to disable the input. Input is enabled at all other
positions.
Track indicator
Track number
background color
Explanation
Lit red Red The input is enabled.
Unlit Gray The input is disabled.
NOTE
•
• The signals from the inputs selected this way will also be sent to the L/R
tracks.
•
•
The levels sent to the L/R tracks are adjusted with
.
To Next Page
