13
Preparations
Supplying power
Power can be supplied three ways using AA batteries, an L battery or USB.
■ Using an L battery
1. Slide the battery in the direction of the arrow while
pressing it toward the recorder.
NOTE
•
• Be careful because the battery case could become loose unexpectedly if
the battery compartment cover screw is not tightened rmly.
•
• Use only one type of batteries (alkaline, NiMH or lithium) at a time.
•
• After loading AA batteries, set "Power Source" to the correct type of bat-
tery. ( →P.20)
•
• If the remaining battery power indicator becomes red, turn the power off
immediately and install new batteries.
■ Using AA batteries
1. Loosen the screw in the battery cover on the bottom.
2. Open the battery compartment cover on the bottom,
remove the battery case, and insert 4 AA batteries.
3. Put the case into the compartment.
4. Close the battery cover and tighten the screw.
To Next Page
