Pannoramic 250 1.15 User’s Guide 5 Troubleshooting and Maintenance
Note:
The base unit has four carrying handles for transporting. Two or four
people can carry the base unit using these carrying handles. To
determine the appropriate number of transporter people, observe the
laws of your country regarding load carrying capacity limitations. You
can find the weight data of the base unit in section 6. Technical Data.
To transport Pannoramic 250 do the following:
1. Switch power supply off (see section 1.1.4 Main parts of the Base Unit) and detach all
other cables.
2. Pull carrying handles out (1) until mechanical stop position (A).
3. Turn carrying handles by 90° (B) towards the base unit to secure them.
4. Now you can transport Pannoramic 250 with the help of another person.
5. After finishing transportation, push carrying handles back into normal position (C).
March 13, 2012 – Rev. 1 3DHISTECH Ltd.
130(135)
