Pannoramic 250 1.15 User’s Guide 2 Installation
2 Installation
Warning!
The installation of Pannoramic 250 must be carried out by trained
professionals! In any other case the warranty will be automatically
voided.
Supplier/Distributor is not liable for any damages caused by an
installation that is not carried out by a professional person.
Only qualified service assistants are allowed to install the hardware and software. The product is
ready for use after installation.
2.1 Control computer ports
The following figure shows the location of the connectors in order to enable easier transportation of
the product for a short distance, by disconnecting cables and detaching hardware components from
each other.
Figure 7 – Ports on control computer
March 13, 2012 – Rev. 1 3DHISTECH Ltd.
23(135)
