Pannoramic 250 1.15 User’s Guide 6 Technical Data
Operating data
Intended site closed room facilities
Electrical protection class I
Internal protection degree IP 20
Electrical safety in compliance with DIN EN 61010-1:2001, DIN EN 61010-2-
101:2002 (IEC 61010-1:2001, IEC 61010-2-101:2002)
Over-voltage category II
Radio interference suppression in accordance with EN 55011 class B
Noise immunity in accordance with EN 61326-2-6:2005
Base unit input voltage 100-240V AC
Power consumption of the complete device 53 VA
Light sources
Halogen lamp (transmitted light operation) Precision-Aligned Pulsed Xenon Light Source
Average service life of halogen lamp 2 x 10
9
flashes
Lamp module for HXP 120 (fluorescent option) 120 W
Average service life of Mercury short arc reflector lamp 2000h
Lumencor light source SPECTRA 7 Light Engine
Average service life of the Lumencor's light source 10 000 h
This User’s Guide describes Lumencor SPECTRA 7 and HXP 120 as light sources. The X-Cite 120
illuminator may also be used as a substitute light source.
Slide identification
Slides are identified by preview camera (VRmagic VRmC-8+ PRO). Barcode area is saved as image and
label is interpreted as a character string, with capability for interpretation of the following types of 1D
and 2D barcodes:
• Interleaved 2 of 5
• Code39 (ASCII encoding)
• Code93 (ASCII encoding)
• Code128 (UCC/EAN128) (ASCII encoding)
March 13, 2012 – Rev. 1
3DHISTECH Ltd. 132(135)
