Pannoramic 250 1.15 User’s Guide 3 Operating Slides and Magazines
3. Slide down the magazine on the input guide rails until it rests on the gear wheels (6) or
magazines.
Figure 14 – Gear wheels
Caution!
Make sure that the magazines are not misplaced, because it can cause
serious damages in the feeding mechanism.
Figure 15 – Misplaced magazine
Note:
The input stack can be filled with a maximum of 9 magazines in
addition to the one in the magazine loader.
March 13, 2012 – Rev. 1 3DHISTECH Ltd.
32(135)
