Pannoramic 250 1.15 User’s Guide 4 Software Description
Objective type
You can select the type and the magnification level of the objectives.
Camera type
Select the correct camera types in Pos. 1 and Pos. 2 fields, then the software automatically
loads the camera settings upon clicking the Test and Apply Camera Settings button.
You can save the settings by clicking .
Note:
The function Enable HXP 120 fluorescent light source shutter is
available only for AxioCam MRm Rev 3. The AxioCam and the HXP 120
must be connected by a trigger cable to enable this function.
Camera Rotation
Caution!
If you have transported the product, or changed the camera, there is a
possibility, that the camera does not display the images properly. If you
experience such problems, contact 3DHISTECH service support. Do not
modify these settings yourself.
