ABB ACQ580 Firmware Manual

Additional parameter data 311
22.74 Motor potentiometer down
source
Binary
src
--1 = 1
22.75 Motor potentiometer ramp time Real 0.0…3600.0 s 10 = 1 s
22.76 Motor potentiometer min value Real -32768.00…32767.00 - 100 = 1
22.77 Motor potentiometer max
value
Real -32768.00…32767.00 - 100 = 1
22.80 Motor potentiometer ref act Real -32768.00…32767.00 - 100 = 1
22.86 Speed reference act 6 Real -30000.00…30000.00 rpm 100 = 1 rpm
22.87 Speed reference act 7 Real -30000.00…30000.00 rpm 100 = 1 rpm
23 Speed reference ramp
23.01 Speed ref ramp input Real -30000.00…30000.00 rpm 100 = 1 rpm
23.02 Speed ref ramp output Real -30000.00…30000.00 rpm 100 = 1 rpm
23.12 Acceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
23.13 Deceleration time 1 Real 0.000…1800.000 s 1000 = 1 s
23.23 Emergency stop time Real 0.000…1800.000 s 1000 = 1 s
23.32 Shape time 1 Real 0.000...1800.000 s 1000 = 1 s
24 Speed reference conditioning
24.01 Used speed reference Real -30000.00…30000.00 rpm 100 = 1 rpm
24.02 Used speed feedback Real -30000.00…30000.00 rpm 100 = 1 rpm
24.03 Speed error filtered Real -30000.0…30000.0 rpm 100 = 1 rpm
24.04 Speed error inverted Real -30000.0…30000.0 rpm 100 = 1 rpm
24.11 Speed correction Real -10000.00…10000.00 rpm 100 = 1 rpm
24.12 Speed error filter time Real 0…10000 ms 1 = 1 ms
25 Speed control
25.01 Torque reference speed
control
Real -1600.0…1600.0 % 10 = 1%
25.02 Speed proportional gain Real 0.00…250.00 - 100 = 1
25.03 Speed integration time Real 0.00…1000.00 s 100 = 1 s
25.04 Speed derivation time Real 0.000…10.000 s 1000 = 1 s
25.05 Derivation filter time Real 0…10000 ms 1 = 1 ms
25.15 Proportional gain em stop Real 1.00…250.00 - 100 = 1
25.53 Torque prop reference Real -30000.0…30000.0 % 10 = 1%
25.54 Torque integral reference Real -30000.0…30000.0 % 10 = 1%
25.55 Torque deriv reference Real -30000.0…30000.0 % 10 = 1%
28 Frequency reference chain
28.01 Frequency ref ramp input Real -500.00…500.00 Hz 100 = 1 Hz
28.02 Frequency ref ramp output Real -500.00…500.00 Hz 100 = 1 Hz
28.11 Ext1 frequency ref1 Analog
src
--1 = 1
28.15 Ext2 frequency ref1 Analog
src
- - 1 = 1
28.21 Constant frequency function PB 00b…11b - 1 = 1
No. Name Type Range Unit FbEq32

ABB ACQ580 Specifications

General

Protection class	IP21, IP55
Ambient temperature range	-15°C to +50°C
Communication protocols	Modbus RTU
Mounting type	Wall mounted
Control method	vector control
Frequency range	0 Hz to 500 Hz
Protection features	Overcurrent, overvoltage, undervoltage, short circuit
