ACS550 User’s Manual 155
Parameters
21 = T1+T3+B – Booster and Time Periods 1 and 3 selected in the timer.
22 =
T2+T3+B – Booster and Time Periods 2 and 3 selected in the timer.
23 =
T1+T2+T3+B – Booster and Time Periods 1, 2 and 3 selected in the timer.
24 =
T4+B – Booster and Time Period 4 selected in the timer.
25 =
T1+T4+B – Booster and Time Periods 1 and 4 selected in the timer.
26 =
T2+T4+B – Booster and Time Periods 2 and 4 selected in the timer.
27 =
T1+T2+T4+B – Booster and Time Periods 1, 2 and 4 selected in the timer.
28 =
T3+T4+B – Booster and Time Periods 3 and 4 selected in the timer.
29 =
T1+T3+T4+B – Booster and Time Periods 1, 3 and 4 selected in the timer.
30 =
T2+T3+T4+B – Booster and Time Periods 2, 3 and 4 selected in the timer.
31 =
T1+2+3+4+B – Booster and Time Periods 1, 2, 3 and 4 selected in the timer.
3627 TIMED FUNC 2 SRC
• See parameter 3626.
3628 TIMED FUNC 3 SRC
• See parameter 3626.
3629 TIMED FUNC 4 SRC
• See parameter 3626.
Code Description
