264 ACS550 User’s Manual
Technical data
Fuses, 208…240 V drives
Fuses, 380…480 V drives
ACS550-x1-
see below
Input current
A
Input power (mains) fuses
IEC 269 gG (A)
UL Class T (A) Bussmann type
-04A6-2 4.6 10
10 JJS-10
-06A6-2 6.6
-07A5-2 7.5
-012A-2 11.8 16
15 JJS-15
-017A-2 16.7 25
25 JJS-25
-024A-2 24.2
30 JJS-30
-031A-2 30.8 40
40 JJS-40
-046A-2 46.2 63
60 JJS-60
-059A-2 59.4
80 JJS-80
-075A-2 74.8 80
100 JJS-100
-088A-2 88.0 100
110 JJS-110
-114A-2 114 125
150 JJS-150
-143A-2 143 200
200 JJS-200
-178A-2 178 250
250 JJS-250
-221A-2 221 315
300 JJS-300
-248A-2 248
350 JJS-350
00467918.xls B
ACS550-x1-
see below
Input current
A
Input power (mains) fuses
IEC 269 gG (A)
UL Class T (A) Bussmann type
-03A3-4 3.3 10
10 JJS-10
-04A1-4 4.1
-05A4-4 5.4
-06A9-4 6.9
-08A8-4 8.8
15 JJS-15
-012A-4 11.9 16
-015A-4 15.4
20 JJS-20
-023A-4 23 25
30 JJS-30
-031A-4 31 35
40 JJS-40
-038A-4 38 50
50 JJS-50
-044A-4 44
60 JJS-60
-045A-4 45
-059A-4 59 63
80 JJS-80
-072A-4 72 80
90 JJS-90
-077A-4 77
100 JJS-100
-078A-4 77
-087A-4 87 125
125 JJS-125
-096A-4 96
-097A-4 97
