ACS550 User’s Manual 285
Technical data
Air flow, 500…600 V drives
The following table lists heat loss and air flow data for 500…600 V drives.
Drive Heat loss Air flow
ACS550-U1- Frame size W
BTU/hr m
3
/h ft
3
/min
-02A7-6 R2 52
178 88 52
-03A9-6 R2 73
249 88 52
-06A1-6 R2 127
434 88 52
-09A0-6 R2 172
587 88 52
-011A-6 R2 232
792 88 52
-017A-6 R2 337
1151 88 52
-022A-6 R3 457
1561 134 79
-027A-6 R3 562
1919 134 79
-032A-6 R4 667
2278 280 165
-041A-6 R4 907
3098 280 165
-052A-6 R4 1117
3815 280 165
-062A-6 R4 1357
4634 280 165
-077A-6 R6 2310
7889 405 238
-099A-6 R6 2310
7889 405 238
-125A-6 R6 2310
7889 405 238
-144A-6 R6 2310
7889 405 238
