ACS550 User’s Manual 53
Control panels
Selecting timed function status indicated through relay output RO 1401
Selecting timed PID1 parameter set 1/2 control 4027
Protections Setting the current and torque limits 2003, 2017
Output signals Selecting the signals indicated through relay output RO Group 14: RELAY OUTPUTS
Selecting the signals indicated through analog output AO
Setting the minimum, maximum, scaling and inversion
Group 15: ANALOG OUTPUTS
Name Description Set parameters
