155
22.27 Constant speed 2 600 600 600 600
22.29 Constant speed 4 1200 1200 1200 1200
22.71 Motor
potentiometer
0 = Disabled 0 = Disabled 0 = Disabled 0 = Disabled
22.73 Motor
potentiometer up
0 = Not used 0 = Not used 0 = Not used 0 = Not used
22.74 Motor
potentiometer
0 = Not used 0 = Not used 0 = Not used 0 = Not used
23.11 Ramp set
selection
6 = DI5 6 = DI5 6 = DI5 0 = Acc/Dec time
1
23.12 Acceleration time
1
20.000s 20.000s 20.000s 20.000s
23.13 Deceleration time
1
20.000s 20.000s 20.000s 20.000s
28.11 Ext1 frequency
ref1
1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled
28.15 Ext1 frequency
ref2
0 = Zero 0 = Zero 0 = Zero 0 = Zero
28.22 Constant
frequency sel1
4 = DI3 4 = DI3 4 = DI3 5 = DI4
28.23 Constant
frequency sel2
5 = DI4 5 = DI4 5 = DI4 6 = DI5
28.71 Freq ramp set
selection
6 = DI5 6 = DI5 6 = DI5 0 = Acc/Dec time
1
30.10 Current limit
actions
0 = No action 0 = No action 0 = No action 0 = No action
30.11 Minimum speed -1500.00 -1500.00 -1500.00 -1500.00
31.11 Fault reset
selection
0 = Not used 0 = Not used 0 = Not used 0 = Not used
40.07 Process PID
operation mode
0 = Off 0 = Off 0 = Off 0 = Off
40.16 Set 1 setpoint 1
source
11 = AI1 percent 11 = AI1 percent 1 = AI1 percent 1 = AI1 percent
40.17 Set 1 setpoint 2
source
0 = Not selected 0 = Not selected 0 = Not selected 0 = Not selected
40.19 Set 1 internal
setpoint sel1
0 = Not selected 0 = Not selected 0 = Not selected 0 = Not selected
40.20 Set 1 internal
setpoint sel2
0 = Not selected 0 = Not selected 0 = Not selected 0 = Not selected
40.32 Set 1 gain 1.00 1.00 1.00 1.00
40.33 Set 1 integration
time
60.0 60.0 60.0 60.0
76.21 PFC
configuration
0=Off 0=Off 0=Off 0=Off
76.25 Number of
motors
11 1 1
76.27 Max number of
motors allowed
11 1 1
99.04 Motor control
mode
1 = Scalar 0 = Vector 0 =
Vector 1 = Scalar
Parameter
96.04 Macro select
ABB standard
(1)
ABB standard
(vector) (17)
Torque control
(26)
3-wire
(11)
