Parameter
96.04 Macro select
Motor potenti-
ometer (13)
Pharma Application
(19)
PID (14) Panel PID (15)
10.24 RO1 source
11 = Ready run 2=Ready run 2=Ready
run
2=Ready run
10.27 RO2 source
7=Running 7=Running
7=Running 7=Running
10.30 RO3 source
15 = Fault (-1) 14 = Fault 15 = Fault (-
1)
15 = Fault (-1)
12.20
AI1 scaled at AI1
max
50.000 1500.000
50.000 50.000
12.30 AI2 scaled at AI2
min
50.000 50.000
50.000 50.000
13.12 AO1 source
2 = Output
frequency
1 = Motor speed used 2 = Output
frequency
2 = Output
frequency
13.18 AO1 source max
50.0 1500.0
50.0 50.0
19.11 Ext1/Ext2 selection
0 = EXT1 0 = EXT1
0 = EXT1 0 = EXT1
19.14 Ext2 control mode
2 = Speed 2 = Speed
2 = Speed 2 = Speed
19.17 Local control mode
0 = No 0 = No 0 = No 0 = No
20.01 Ext1 commands
2 = In1 Start;
In2 Dir
4 = In1P Start; In2 Stop
1 = In1 Start 1 = In1 Start
20.03 Ext1 in1 source
2 = DI1 2 = DI1
2 = DI1 2 = DI1
20.04 Ext1 in2 source
3 = DI2 3 = DI2
0 = Always off 0 = Always off
20.05 Ext1 in3 source
0 = Always off 0 = Always off
0 = Always off 0 = Always off
20.06 Ext2 commands
0 = Not selected 0 = Not selected 0 = Not
selected
0 = Not selected
20.08 Ext2 in1 source
0 = Always off 0 = Always off
0 = Always off 0 = Always off
20.09 Ext2 in2 source
0 = Always off 0 = Always off
0 = Always off 0 = Always off
20.12
Run enable 1
source
7 = DI6 1 = Selected
6 = DI5 6 = DI5
21.03 Stop mode
1 =Coast 1 = Coast
0 = Coast 0 = Coast
22.11 Ext1 speed ref1
15 = Motor
potentiometer
1 = AI1 scaled
16 = PID 16 = PID
22.18 Ext2 speed ref1
0 = Zero 0 = Zero
0 = Zero 0 = Zero
22.21 Constant speed
function
0b000 0b0001
0b0000 0b0000
22.22
Constant speed
sel1
6 = DI5 4 = DI3
5 = DI4 5 = DI4
22.23
Constant speed
sel2
0 = Always off 5 = DI4
0 = Always off 0 = Always off
22.24
Constant speed
sel3
0 = Always off 5 = DI5
0 = Always off 0 = Always off
22.26 Constant speed 1
300 600
300 300
22.27 Constant speed 2
600 900
600 600
