ABB ACS560 - Page 157

157
22.29 Constant speed 4
1200 1480
1200 1200
22.71
Motor potentiometer
function
1 = Enabled (init
at stop /power-
0 = Disabled
0 = Disabled 0 = Disabled
22.73 Motor potentiometer
up source
4 = DI3 0 = Not used 0 = Not used 0 = Not used
22.74 Motor potentiometer
down source
5 = DI4 0 = Not used 0 = Not used 0 = Not used
23.11 Ramp set selection 0 = Acc/Dec
time 1
0 = Acc/Dec time 1 0 = Acc/Dec
time 1
0 = Acc/Dec time
1
23.12 Acceleration time 1 20.000s 300s 20.000s 20.000s
23.13 Deceleration time 1 20.000s 300s 20.000s 20.000s
28.11 Ext1 frequency ref1 15 = Motor
potentiometer
1 = AI1 scaled 16 = PID 16 = PID
28.15 Ext1 frequency ref2 0 = Zero 0 = Zero 0 = Zero 0 = Zero
28.22 Constant frequency
sel1
6 = DI5 4 = DI3 5 = DI4 5 = DI4
28.23 Constant frequency
sel2
0 = Always off 5 = DI4 0 = Always off 0 = Always off
28.71 Freq ramp set
selection
0 = Acc/Dec
time 1
6 = DI5 0 = Acc/Dec
time 1
0 =
Acc/Dec time
1
30.10 Current limit actions 0 = No action 0 = No action 0 = No action 0 = No action
30.11 Minimum speed -1500.00 -1500.00 -1500.00 -1500.00
31.11 Fault reset selection 0 = Not used 0 = Not used 0 = Not used 0 = Not used
40.07 Process PID
operation mode
0 = Off 0 = Off 2 = On when
drive running
2 = On when
drive running
40.16 Set 1 setpoint 1
source
11 = AI1 percent 11 = AI1 percent 11 = AI1
percent
13 = Control
panel (ref saved)
40.17 Set 1 setpoint 2
source
0 = Not selected 0 = Not selected 2 = Internal
setpoint
0 = Not selected
40.19 Set 1 internal
setpoint sel1
0 = Not selected 0 = Not selected 3 = DI2 0 = Not selected
40.20 Set 1 internal
setpoint sel2
0 = Not selected 0 = Not selected 4 = DI3 0 = Not selected
40.32 Set 1 gain 1.00 1.00 1.00 1.00
40.33 Set 1 integration
time
60.0 60.0 60.0 60.0
76.21 PFC configuration 0=Off 0=Off 0=Off 0=Off
76.25 Number of motors 11 11
76.27 Max number of
motors allowed
11 11
99.04 Motor control mode 1 = Scalar 0 = Vector
1 = Scalar 1 = Scalar
Parameter
96.04 Macro select
Motor potenti-
ometer (13)
Pharma Application
(19)
PID (14) Panel PID (15)
