158
Parameter
96.04 Macro select
PFC (16) SPFC (18)
Plastic Extrusion
(20)
Jigar (30)
10.24 RO1 source 7=Running 7=Running 11 = Zero speed 11 = Ready run
10.27 RO2 source 15 = Fault (-1) 43 = PFC1
7=Running 7=Running
10.30 RO3 source 46 = PFC2 46 = PFC2 14 = Fault 14 = Fault (-1)
12.20
AI1 scaled at AI1
max
50.000 50.000 1500.000 1500.000
12.30
AI2 scaled at AI2
max
50.000 50.000 50.000 100.000
13.12 AO1 source
2 = Output
frequency
2 = Output
frequency
1 = Motor speed
used
1 = Output
frequency
13.18 AO1 source max 50.0 50.0 1500.0 50.0
19.11 Ext1/Ext2 selection 1 = DI3 5 = DI3 0 = EXT1 0 = DI3
19.14 Ext2 control mode 2 = Speed 2 = Speed 2 = Speed 2 = Torque
19.17 Local control mode 0 = No 0 = No 1 = Yes 1 = No
20.01 Ext1 commands 1 = In1 Start 1 = In1 Start 1 = In1 Start
1 = In1 Start fwd;
In2 Start rev
20.03 Ext1 in1 source 2 = DI1 2 = DI1 2 = DI1 2 = DI1
20.04 Ext1 in2 source 0 = Always off
0 = Always off 3 = DI2 3 = DI2
20.05 Ext1 in3 source 0 = Always off 0 = Always off 0 = Always off 0 = Always off
20.06 Ext2 commands 1 = In1 Start 1 = In1 Start 0 = Always off 0 = In1 Start
20.08 Ext2 in1 source 7 = DI6 7 = DI6 0 = Always off 0 = DI1
20.09 Ext2 in2 source 0 = Always off 0 = Always off 0 = Always off 0 = Always off
20.12
Run enable 1
source
3 = DI2 3 = DI2 1 = Selected 1 = Selected
21.03 Stop mode 0 = Coast 0 = Coast 1 = Ramp 1 = Coast
22.11 Ext1 speed ref1 1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled
22.18 Ext2 speed ref1 16 = PID 0 = Zero 0 = Zero 0 = Zero
22.21 Constant speed
function
0b0001 0b0001 0b0001 0b0001
22.22 Constant speed sel1 0 = Always off 4 = DI3 4 = DI3 4 = Always off
22.23 Constant speed sel2 0 = Always off 5 = DI4 5 = DI4 5 = Always off
22.24 Constant speed sel3 0 = Always off 0 = Always off 0 = Always off 0 = Always off
22.26 Constant speed 1 300.00 300.00 300.00 300.00
22.27 Constant speed 2 600.00 600.00 600.00 600.00
