ABB ACS560 - Page 159

159
22.29 Constant speed 4 1200.00 1200.00 1200.00 1200.00
22.71
Motor potentiometer
function
0 = Disabled 0 = Disabled 0 = Disabled 0 = Disabled
22.73 Motor potentiometer
up source
0 = Not used 0 = Not used 0 = Not used 0 = Not used
22.74 Motor potentiometer
down source
0 = Not used 0 = Not used 0 = Not used 0 = Not used
23.11 Ramp set selection 0 = Acc/Dec
time 1
6 = DI5 6 = DI5 6 = Acc/Dec time 1
23.12 Acceleration time 1 20.000s 20.000s 20.000s 20.000s
23.13 Deceleration time 1 20.000s 20.000s 20.000s 20.000s
26.11 Torque ref1 source 0 = Zero 0 = Zero 0 = Zero 2 = AI2 scaled
28.11 Ext1 frequency ref1 1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled 1 = AI1 scaled
28.15 Ext1 frequency ref2 16 = PID 16 = PID 0 = Zero 0 = Zero
28.22 Constant frequency
sel1
0 = Always off 0 = Always off 4 = DI3 4 = DI3
28.23 Constant frequency
sel2
0 = Always off 0 = Always off 5 = DI4 5 = DI4
28.71 Freq ramp set
selection
0 = Acc/Dec
time 1
0 = Acc/Dec time
1
6 = DI5 6 = DI5
30.10 Current limit actions 0 = No action 0 = No action 1 = Warning 1 = No action
30.11 Minimum speed -1500.00 -1500.00 0.00 0.00
31.11 Fault reset selection 0 = Not used 0 = Not used 0 = Not used 0 = Not used
40.07 Process PID
operation mode
2 = On when
drive running
2 = On when
drive running
0 = Off 0 = Off
40.16 Set 1 setpoint 1
source
11 = AI1
percent
11 = AI1 percent 11 = AI1 percent 11 = AI1 percent
40.17 Set 1 setpoint 2
source
0 = Not
selected
0 = Not selected 0 = Not selected 0 = Not selected
40.19 Set 1 internal
setpoint sel1
0 = Not
selected
0 = Not selected 0 = Not selected 0 = Not selected
40.20 Set 1 internal
setpoint sel2
0 = Not
selected
0 = Not selected 0 = Not selected 0 = Not selected
40.32 Set 1 gain 2.50 2.50 1.00 1.00
40.33 Set 1 integration
time
3.0 3.0 60.0 s 60.0 s
76.21 PFC configuration 2=PFC 2=SPFC 0=Off 0=Off
76.25 Number of motors 22 1 1
76.27 Max number of
motors allowed
22 1 1
99.04 Motor control mode
1 = Scalar 1 = Scalar 0 = Vector 0 = Vector
Parameter
96.04 Macro select
PFC (16) SPFC (18)
Plastic Extrusion
(20)
Jigar (30)
