ABB ACS800-17LC User Manual

Technical data
151
Main circuit DC fuses
ACS800-17LC-0950-7 720 3 170M7059 PC33UD69V1250TF
ACS800-17LC-1240-7 941 3 170M7060 PC33UD69V1400TF
ACS800-17LC-1840-7 1397 3 170M7062 PC44UD75V20CTQ
ACS800-17LC-2430-7 1843 6 170M7060 PC33UD69V1400TF
ACS800-17LC-3620-7 2736 6 170M7062 PC44UD75V20CTQ
ACS800-17LC-4630-7 3648 12 170M7060 PC33UD69V1400TF
ACS800-17LC-5300-7 4104 9 170M7062 PC44UD75V20CTQ
ACS800-17LC-5960-7 4560 15 170M7060 PC33UD69V1400TF
Drive type Supply output (IEC and UL Recognized) Inverter input (IEC and UL Recognized)
Qty Bussmann Ferraz Shawmut Qty Bussmann Ferraz Shawmut
U
N
= 400 V
ACS800-17LC-0110-3 - - - - - -
ACS800-17LC-0140-3 - - - - - -
ACS800-17LC-0170-3 - - - - - -
ACS800-17LC-0200-3 - - - - - -
ACS800-17LC-0260-3 - - - - - -
ACS800-17LC-0350-3 - - - - - -
ACS800-17LC-0430-3 - - - - - -
ACS800-17LC-0580-3 - - - - - -
ACS800-17LC-0870-3 4 170M6415 PC33UD69V1100TF 4 170M6415 PC33UD69V1100TF
ACS800-17LC-1130-3 4 170M6419 PC73UD69V1600TF 4 170M6419 PC73UD69V1600TF
ACS800-17LC-1680-3 6 170M6419 PC73UD69V1600TF 6 170M6419 PC73UD69V1600TF
ACS800-17LC-2220-3 8 170M6419 PC73UD69V1600TF 8 170M6419 PC73UD69V1600TF
ACS800-17LC-3300-3 12 170M6419 PC73UD69V1600TF 12 170M6419 PC73UD69V1600TF
U
N
= 500 V
ACS800-17LC-0120-5 - - - - - -
ACS800-17LC-0170-5 - - - - - -
ACS800-17LC-0210-5 - - - - - -
ACS800-17LC-0250-5 - - - - - -
ACS800-17LC-0310-5 - - - - - -
ACS800-17LC-0410-5 - - - - - -
ACS800-17LC-0520-5 - - - - - -
ACS800-17LC-0690-5 - - - - - -
ACS800-17LC-1030-5 4 170M6415 PC33UD69V1100TF 4 170M6415 PC33UD69V1100TF
ACS800-17LC-1350-5 4 170M6419 PC73UD69V1600TF 4 170M6419 PC73UD69V1600TF
ACS800-17LC-2000-5 6 170M6419 PC73UD69V1600TF 6 170M6419 PC73UD69V1600TF
ACS800-17LC-2640-5 8 170M6419 PC73UD69V1600TF 8 170M6419 PC73UD69V1600TF
ACS800-17LC-3930-5 12 170M6419 PC73UD69V1600TF 12 170M6419 PC73UD69V1600TF
U
N
= 690 V
ACS800-17LC-0130-7 - - - - - -
ACS800-17LC-0170-7 - - - - - -
ACS800-17LC-0210-7 - - - - - -
Drive type Input
current
AC fuse information (aR IEC and UL Recognized)
Qty Bussmann Ferraz Shawmut
