ABB ACS800-17LC User Manual

Dimensions
171
Dimensions
What this chapter contains
This chapter contains example dimension drawings and a table of dimensions.
Table of dimensions
Drive type Height 1 Height 2 Width 1
(basic)
Width 2
(+H353)
Width 3
(+H359)
mm mm mm mm mm
U
N
= 400 V
ACS800-17LC-0110-3 2003 2315 1200 1500 300
ACS800-17LC-0140-3 2003 2315 1200 1500 300
ACS800-17LC-0170-3 2003 2315 1200 1500 300
ACS800-17LC-0200-3 2003 2315 1200 1500 300
ACS800-17LC-0260-3 2003 2315 1200 1500 300
ACS800-17LC-0350-3 2003 2315 1200 1500 300
ACS800-17LC-0430-3 2003 2315 1200 1500 300
ACS800-17LC-0580-3 2003 2315 1200 1500 300
ACS800-17LC-0870-3 2003 2315 1900 2300 300
ACS800-17LC-1130-3 2003 2315 1900 2300 300
ACS800-17LC-1680-3 2003 2315 3100 3700 400
ACS800-17LC-2220-3 2003 2315 3200 4000 600
ACS800-17LC-3300-3 2003 2315 5000 6000 400 + 400
U
N
= 500 V
ACS800-17LC-0120-5 2003 2315 1200 1500 300
ACS800-17LC-0170-5 2003 2315 1200 1500 300
ACS800-17LC-0210-5 2003 2315 1200 1500 300
ACS800-17LC-0250-5 2003 2315 1200 1500 300
ACS800-17LC-0310-5 2003 2315 1200 1500 300
ACS800-17LC-0410-5 2003 2315 1200 1500 300
ACS800-17LC-0520-5 2003 2315 1200 1500 300
ACS800-17LC-0690-5 2003 2315 1200 1500 300
ACS800-17LC-1030-5 2003 2315 1900 2300 300
ACS800-17LC-1350-5 2003 2315 1900 2300 300
ACS800-17LC-2000-5 2003 2315 3100 3700 400
ACS800-17LC-2640-5 2003 2315 3200 4000 600
ACS800-17LC-3930-5 2003 2315 5000 6000 400 + 400
U
N
= 690 V
ACS800-17LC-0130-7 2003 2315 1200 1500 300
ACS800-17LC-0170-7 2003 2315 1200 1500 300
ACS800-17LC-0210-7 2003 2315 1200 1500 300
ACS800-17LC-0280-7 2003 2315 1200 1500 300
