ABB ACS880-104

Parameters 335
Output frequency 01.06 Output frequency (page 152). 3
Motor current 01.07 Motor current (page 152). 4
Motor torque 01.10 Motor torque (page 152). 6
DC voltage 01.11 DC voltage (page 152). 7
Power inu out 01.14 Output power (page 153). 8
Speed ref ramp in 23.01 Speed ref ramp input (page 257). 10
Speed ref ramped 23.02 Speed ref ramp output (page 257). 11
Speed ref used 24.01 Used speed reference (page 263). 12
Torq ref used 26.02 Torque reference used (page 279). 13
Freq ref used 28.02 Frequency ref ramp output (page 285). 14
Process PID out 40.01 Process PID output actual (page 341). 16
Process PID fbk 40.02 Process PID feedback actual (page 341). 17
Process PID act 40.03 Process PID setpoint actual (page 341). 18
Process PID dev 40.04 Process PID deviation actual (page 341). 19
Other Source selection (see Terms and abbreviations
on page 148). -
36.02 PVL filter time Defines a filtering time for the peak value logger. See
parameter 36.01 PVL signal source.
2.00 s
0.00 … 120.00 s Peak value logger filtering time. 100 = 1 s
36.06 AL2 signal source Selects the signal to be monitored by amplitude logger 2. The
signal is sampled at 200 ms intervals, and can be scaled
using parameter 36.07 AL2 signal scaling.
The results are displayed by parameters 36.40…36.49. Each
parameter represents an amplitude range, and shows what
portion of the samples fall within that range.
Amplitude logger 2 can be reset using parameter 36.09 Reset
loggers. The logger is also reset whenever the signal source
or scaling is changed. The date and time of the last reset are
stored into parameters 36.50 and 36.51 respectively.
Ambient
temperature
Zero None (amplitude logger 2 disabled). 0
Motor speed used 01.01 Motor speed used (page 152). 1
Output frequency 01.06 Output frequency (page 152). 3
Motor current 01.07 Motor current (page 152). 4
Motor torque 01.10 Motor torque (page 152). 6
DC voltage 01.11 DC voltage (page 152). 7
Power inu out 01.14 Output power (page 153). 8
Speed ref ramp in 23.01 Speed ref ramp input (page 257). 10
Speed ref ramped 23.02 Speed ref ramp output (page 257). 11
Speed ref used 24.01 Used speed reference
(page 263). 12
Torq ref used 26.02 Torque reference used (page 279). 13
Freq ref used 28.02 Frequency ref ramp output (page 285). 14
Process PID out 40.01 Process PID output actual (page 341). 16
Process PID fbk 40.02 Process PID feedback actual (page 341). 17
Process PID act 40.03 Process PID setpoint actual (page 341). 18
Process PID dev 40.04 Process PID deviation actual (page 341). 19
No. Name/Value Description Def/FbEq16
