ABB ACS880-104

Parameters 345
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
40.20 Set 1 internal
setpoint sel2
Selects, together with 40.19 Set 1 internal setpoint sel1, the
internal setpoint out of the presets defined by parameters
40.21…40.24. See table at 40.19 Set 1 internal setpoint sel1.
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see
Terms and abbreviations on page 148). -
40.21 Set 1 internal
setpoint 1
Defines process setpoint preset 1. See parameter 40.19 Set
1 internal setpoint sel1.
The unit is selected by parameter 40.12 Set 1 unit selection.
0.00
-32768.00 …
32767.00
Process setpoint preset 1. 1 = 1 unit
40.22 Set 1 internal
setpoint 2
Defines process setpoint preset 2. See parameter 40.19 Set
1 internal setpoint sel1.
The unit is selected by parameter 40.12 Set 1 unit selection.
0.00
-32768.00 …
32767.00
Process setpoint preset 2. 1 = 1 unit
40.23 Set 1 internal
setpoint 3
Defines process setpoint preset 3. See parameter 40.19 Set
1 internal setpoint sel1.
The unit is selected by parameter 40.12 Set 1 unit selection.
0.00
-32768.00 …
32767.00
Process setpoint preset 3. 1 = 1 unit
40.24 Set 1 internal
setpoint 4
Defines process setpoint preset 4. See parameter 40.19 Set
1 internal setpoint sel1.
The unit is selected by parameter 40.12 Set 1 unit selection.
0.00
-32768.00 …
32767.00
Process setpoint preset 4. 1 = 1 unit
No. Name/Value Description Def/FbEq16
