358 Parameters
44.06 Brake control
enable
Activates/deactivates (or selects a source that
activates/deactivates) the mechanical brake control logic.
0 = Brake control inactive
1 = Brake control active
Not selected
Not selected 0. 0
Selected 1. 1
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 2
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 10
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 11
Other [bit] Source selection (see Terms and abbreviations on page 148). -
44.07 Brake acknowledge
selection
Activates/deactivates (and selects the source for) brake
open/close status (acknowledgement) supervision.
When a brake control error (unexpected state of the
acknowledgement signal) is detected, the drive reacts as
defined by parameter 44.17 Brake fault function.
0 = Brake closed
1 = Brake open
No
acknowledge
Off 0. 0
On 1. 1
No acknowledge Brake open/closed supervision disabled. 2
DI1 Digital input DI1 (10.02 DI delayed status, bit 0). 3
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 4
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 5
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 6
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 7
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 8
DIO1 Digital input/output DIO1 (
11.02 DIO delayed status, bit 0). 11
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 12
Other [bit] Source selection (see Terms and abbreviations on page 148). -
44.08 Brake open delay Defines the brake open delay, ie. the delay between the
internal open brake command and the release of motor speed
control. The delay timer starts when the drive has magnetized
the motor and increased the motor torque to the level
required for brake release (parameter 44.03 Brake open
torque reference). Simultaneously with the timer start, the
brake control logic energizes the brake control output and the
brake starts to open.
Set this parameter to the value of mechanical opening delay
specified by the brake manufacturer.
0.00 s
0.00 … 5.00 s Brake open delay. 100 = 1 s
No. Name/Value Description Def/FbEq16
