ABB ACS880-104

Parameters 375
Frequency The scaling is defined by parameter 46.02 Frequency scaling.5
50.05 FBA A ref2 type Selects the type and scaling of reference 2 received from
fieldbus adapter A.
See parameter 50.04 FBA A ref1 type.
Auto
50.07 FBA A actual 1 type Selects the type/source and scaling of actual value 1
transmitted to the fieldbus network through fieldbus adapter
A.
Note: Fieldbus-specific communication profiles may use
different scalings. For more information, see the manual of
the fieldbus adapter.
Auto
Auto Type/source and scaling follow the type of reference 1
selected by parameter 50.04 FBA A ref1 type. See the
individual settings below for the sources and scalings.
0
Transparent The value selected by parameter 50.10 FBA A act1
transparent source is sent as actual value 1. No scaling is
applied (the 16-bit scaling is 1 = 1 unit).
1
General The value selected by parameter 50.10 FBA A act1
transparent source is sent as actual value 1 with a 16-bit
scaling of 100 = 1 unit (ie. integer and two decimals).
2
Torque 01.10 Motor torque is sent as actual value 1. The scaling is
defined by parameter 46.03 Torque scaling.
3
Speed 01.01 Motor speed used is sent as actual value 1. The scaling
is defined by parameter 46.01 Speed scaling.
4
Frequency 01.06 Output frequency is sent as actual value 1. The scaling
is defined by parameter 46.02 Frequency scaling.
5
Position Motor position is sent as actual value 1. See parameter 90.06
Motor position scaled.
6
50.08 FBA A actual 2 type Selects the type/source and scaling of actual value 2
transmitted to the fieldbus network through fieldbus adapter
A.
See parameter 50.07 FBA A actual 1 type.
Auto
50.09 FBA A SW
transparent source
Selects the source of the fieldbus status word when the
fieldbus adapter is set to a transparent communication profile
eg. by its configuration parameters (group 51 FBA A settings
).
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on page 148). -
50.10 FBA A act1
transparent source
When parameter 50.07 FBA A actual 1 type is set to
Transparent or General, this parameter selects the source of
actual value 1 transmitted to the fieldbus network through
fieldbus adapter A.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on page 148). -
50.11 FBA A act2
transparent source
When parameter 50.08 FBA A actual 2 type is set to
Transparent or General, this parameter selects the source of
actual value 2 transmitted to the fieldbus network through
fieldbus adapter A.
Not selected
Not selected No source selected. -
Other Source selection (see Terms and abbreviations on page 148). -
No. Name/Value Description Def/FbEq16
