Parameters 415
Other Source selection (see Terms and abbreviations on page 148). -
62.46 Data set 1 data 2
selection
Defines a target for the data received as word 2 of data set 1.
See also parameter 62.96 Data set 1 data 2 value.
For the selections, see parameter 62.45 Data set 1 data 1
selection.
None
62.47 Data set 1 data 3
selection
See parameter 62.45 Data set 1 data 1 selection. None
…… … …
62.50 Data set 3 data 3
selection
See parameter 62.45 Data set 1 data 1 selection. None
62.51 Data set 10 data 1
selection
Parameters 62.51…62.74 define a target for the data
received in data sets 10, 12, 14, 16, 18, 20, 22 and 24 from
the external controller.
Parameters 62.101…62.124 display the data received from
the external controller in integer format, and can be used as
sources by other parameters.
For example, this parameter selects a target for word 1 of
data set 10. Parameter 62.101 Data set 10 data 1 value
displays the received data in integer format, and can also be
used as a source by other parameters.
None
None None. 0
CW 16bit Control Word (16 bits) 1
Ref1 16bit Reference REF1 (16 bits) 2
Ref2 16bit Reference REF2 (16 bits) 3
Other Source selection (see Terms and abbreviations on page 148). -
62.52 Data set 10 data 2
selection
Defines a target for the data received as word 2 of data set
10.
See also parameter 62.102 Data set 10 data 2 value.
For the selections, see parameter 62.51 Data set 10 data 1
selection.
None
62.53 Data set 10 data 3
selection
Defines a target for the data received as word 3 of data set
10.
See also parameter 62.103 Data set 10 data 3 value.
For the selections, see parameter 62.51 Data set 10 data 1
selection.
None
62.54 Data set 12 data 1
selection
See parameter 62.51 Data set 10 data 1 selection. None
…… … …
62.74 Data set 24 data 3
selection
See parameter 62.51 Data set 10 data 1 selection. None
62.95 Data set 1 data 1
value
Displays (in integer format) the data received from the
external controller as word 1 of data set 1.
A target for this data can be selected by parameter 62.45
Data set 1 data 1 selection. The value can also be used as a
source by another parameter.
0
0…65535 Data received as word 1 of data set 1.
No. Name/Value Description Def/FbEq16
