450 Parameters
DI2 Digital input DI2 (10.02 DI delayed status, bit 1). 3
DI3 Digital input DI3 (10.02 DI delayed status, bit 2). 4
DI4 Digital input DI4 (10.02 DI delayed status, bit 3). 5
DI5 Digital input DI5 (10.02 DI delayed status, bit 4). 6
DI6 Digital input DI6 (10.02 DI delayed status, bit 5). 7
DIO1 Digital input/output DIO1 (11.02 DIO delayed status, bit 0). 8
DIO2 Digital input/output DIO2 (11.02 DIO delayed status, bit 1). 9
Other Source selection (see Terms and abbreviations on page 148). -
85.61 Convex coef 1 Defines convex coefficient for the segment 1 of the curves
plot.
0.00
-10.00...10.00 Convex coef 1. 10 = 1
85.62 Convex coef 2 Defines convex coefficient for the segment 2 of the curves
plot.
0.00
-10.00...10.00 Convex coef 2. 10 = 1
85.63 Convex coef 3 Defines convex coefficient for the segment 3 of the curves
plot.
0.00
-10.00...10.00 Convex coef 3. 10 = 1
85.64 Convex coef 4 Defines convex coefficient for the segment 4 of the curves
plot.
0.00
-10.00...10.00 Convex coef 4. 10 = 1
85.65 Convex coef 5 Defines convex coefficient for the segment 5 of the curves
plot.
0.00
-10.00...10.00 Convex coef 5. 10 = 1
85.66 Convex coef 6 Defines convex coefficient for the segment 6 of the curves
plot.
0.00
-10.00...10.00 Convex coef 6. 10 = 1
85.67 Convex coef 7 Defines convex coefficient for the segment 7 of the curves
plot.
0.00
-10.00...10.00 Convex coef 7. 10 = 1
85.71 Aux input data 1 Defines auxiliary parameter that can be used as a source
data, e.g. for the pump curve input.
0.00
-32000.00...
32000.00
Auxiliary input data 1. 10 = 1
85.72 Aux input data 2 Defines auxiliary parameter that can be used as a source
data, e.g. for the pump curve input.
0.00
-32000.00...
32000.00
Auxiliary input data 2. 10 = 1
85.79 Function type Selects the axis of Q-H pump curve that can be interpreted as
the output.
The user can choose the function to calculate either actual
Flow estimate out of input Head measurement or actual Head
estimate out of input Flow measurement.
Flowrate
estimation
Flowrate estimation Function output is the flow estimate calculated from the user
given input interpreted as the total dynamic head
measurement.
No. Name/Value Description
Def/FbEq16
