476 Parameters
95.13 Reduced run mode (Only visible with a BCU control unit)
Specifies the number of inverter modules available.
This parameter must be set if reduced run is required. A value
other than 0 activates the reduced run function.
If the control program cannot detect the number of modules
specified by this parameter, a fault (5695 Reduced run) is
generated.
See section Reduced run function (page 128).
0 = Reduced run disabled
1…12 = Number of modules available
0
0…65535 Number of inverter modules available -
95.14 Connected modules (Only visible with a BCU control unit)
Shows which of the parallel-connected inverter modules have
been detected by the control program.
-
0000h…FFFFh Inverter modules connected. 1 = 1
95.15 Special HW
settings
Contains hardware-related settings that can be enabled and
disabled by toggling the specific bits.
Note: The installation of the hardware specified by this
parameter may require derating of drive output, or impose
other limitations. Refer to the hardware manual of the drive.
-
0000b…0111b Hardware options configuration word. 1 = 1
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Module 1 1 = Module 1 has been detected.
1 Module 2 1 = Module 2 has been detected.
…… …
11 Module 12 1 = Module 12 has been detected.
12…15 Reserved
Bit Name Information
0 EX motor 1 = The driven motor is an Ex motor provided by ABB for potentially
explosive atmospheres. This sets the required minimum switching
frequency for ABB Ex motors. Note: For non-ABB Ex motors,
contact your local ABB representative.
1 ABB sine filter 1 = An ABB sine filter is connected to the output of the drive/inverter.
2 High speed mode 1 = Minimum switching frequency limit adaptation to output
frequency active. This setting improves control performance at high
output frequencies (typically above 120 Hz).
3 Custom sine filter 1 = A custom sine filter is connected to the output of the
drive/inverter. See also parameters 97.01, 97.02, 99.18, 99.19.
4…15 Reserved
