410 Parameters
Manual_Safebus The FSO module expects an external STO
acknowledgement signal either from a digital
input or from the safety fieldbus after the
STO, SSE or SS1 request has been
removed and the stop function is completed
(output defined by parameter FSOGEN.11
STO completed output is active).
STO.11 STO input A Sets the digital input that is connected to the
primary input of the STO function.
DI X113:1 &
X114:1
None No input connected
DI X113:1 & X114:1 Redundant input X113:1 & X114:1
DI X113:2 & X114:2 Redundant input X113:2 & X114:2
DI X113:3 & X114:3 Redundant input X113:3 & X114:3
DI X113:4 & X114:4 Redundant input X113:4 & X114:4
DI X113:1 Single input X113:1
DI X113:2 Single input X113:2
DI X113:3 Single input X113:3
DI X113:4 Single input X113:4
DI X114:1 Single input X114:1
DI X114:2 Single input X114:2
DI X114:3 Single input X114:3
DI X114:4 Single input X114:4
STO.12 STO input B Sets the digital input that is connected to the
secondary input of the STO function. The
secondary input is mostly used for the
cascade connection.
See parameters SAFEIO.12 Cascade A and
SAFEIO.13 Cascade B.
None
None No input connected
DI X113:1 & X114:1 Redundant input X113:1 & X114:1
DI X113:2 & X114:2 Redundant input X113:2 & X114:2
DI X113:3 & X114:3 Redundant input X113:3 & X114:3
DI X113:4 & X114:4 Redundant input X113:4 & X114:4
DI X113:1 Single input X113:1
DI X113:2 Single input X113:2
DI X113:3 Single input X113:3
DI X113:4 Single input X113:4
DI X114:1 Single input X114:1
DI X114:2 Single input X114:2
DI X114:3 Single input X114:3
DI X114:4 Single input X114:4
Index Name/Value Description Factory
default
