16. Assign the device name (defined in step 11) to the adapter module:
• In the hardware configuration, click FSPS.
• In the PLC menu, select Ethernet, and select Assign Device Name.
• Click the Update button.
• Click the available device with the correct MAC address to which the device name
will be assigned.
• Click Assign name. This assigns the name to the FSPS-21 module.
• Click Close.
PROFIsafe 157
