DefaultDescriptionName/ValueNo.
N/AThese parameters are not used by the adapter module
when the module is configured for PROFINET IO.
Reserved15
...
18
99Defines the scaling for reference 1 and actual 1 with
Transparent 16 profile. (Protocol.Profile = PNIO T16)
T16 scale19
Scaling also depends on the selected Reference type
on 50.04 FBA A Ref 1 type and 50.34 FBA B Ref 1
type and 50.07 and 50.37 for the actual 1.
Ref type = Transparent
FBA_A/B_Ref1 = Ref1_from_PLC * (T16_Scale + 1)
Ref type = General
FBA_A/B_Ref1 = Ref1_from_PLC * (T16_Scale + 1)
/ 100
Reference multiplier/actual value divisor0…65535
0 = Unknown
Read-only. Indicates the telegram type selected for
PROFINET IO communication. The adapter module
automatically detects the telegram type defined in the
PLC.
For more information on the supported PPO message
types, see section PPO types (page 89).
Telegram type20
Cyclical communication between the master and the
module has not been established yet.
0 = Unknown
PPO3 selected3 = PPO3
PPO4 selected4 = PPO4
PPO6 selected6 = PPO6
PPO7 selected7 = PPO7
ST1 selected8 = ST1
ST2 selected9 = ST2
0 = Enabled
Disables the PROFIdrive alarm mechanism which
generates alarms in case of drive faults.
But the standard PROFINET alarms are still sent.
For more information on the diagnostics and alarm
mechanism for PROFIdrive, see section Diagnostic
and alarm mechanism (page 107).
Diagnostic alarm21
PROFIdrive alarms are enabled.0 = Enabled
PROFIdrive alarms are disabled.1 = Disabled
1 = 16bitDefines the preferred data type of mapped parameters
when mapping is done through PROFIdrive paramet-
ers.
Map selection22
Note:
Note: Supported with ACS580 and ACS880 drives
only.
32 bits0 = 32bit
16 bits1 = 16bit
PROFINET IO – Start-up 51
