DefaultDescriptionName/ValueNo.
N/AThis parameter is not used by the adapter module
when the module is configured for PROFINET IO.
Reserved23
0Sets the PROFIsafe destination address, that is, the
address of the FB module in the safety communication
network.
F Destination Address24
Note:
This address must be the same as is set in the F-
Parameters for the PROFIsafe module properties
(F_Dest_Add).
For more information, see section Configuring the
safety PLC (page 126).
0Allows defining the PROFINET station name.PN Name Index25
By default this value is 0 and the station name is set
from the network. When the value is set to other than
0, the PROFINET station name is overwritten in the
format “abbdrive-xx”, where xx is the value of the
parameter name index.
Example: Setting this value to 12 results in the name
“abbdrive-12”.
Note:
During every boot the FSPS-21 module checks the
value of PN Name Index,
• If the value is not Zero then the active PN Name In-
dex overrides the PROFINET station name.
• If the new name is set by DCP Set command as
permanent, the new name is used and stored to
flash. The PN Name Index parameter value is not
changed, so after next boot, the name is taken ac-
cording to the PN Name Index.
• If the new name is set by DCP Set command as
temporary, the new name is used and the empty
name is stored to flash. The PN Name Index para-
meter value is not changed, so after next boot name
is taken according to the PN Name Index.
• The PROFINET DCP factory reset also resets the
PN Name Index value to default (0).
0...65535
0 = DoneValidates any changed adapter module configuration
parameter settings. After refreshing, the value reverts
automatically to 0 = Done.
FBA A/B par refresh27
Note:
This parameter cannot be changed while the drive is
running.
Refreshing done0 = Done
Refreshing1 = Refresh
52 PROFINET IO – Start-up
