ABB LGR GLA351 Series User Manual

USER MANUAL | ICOS | INSTRUCTIONS | UM/ICOS-EN REV. B.2
43
Table 9 describes fault criteria for the Analyzer Alarms.
‘A’ refers to Laser 1 and ‘B’ refers to Laser 2. Not all analyzers are equipped
with 2 lasers.
Table 9: Fault Criteria for Analyzer Alarms
Status
Sensor Read
Fault Condition
Description
4
Data Health
(A/B)
Fit is not
optimal
The laser fitting condition is poor. Occurs when
fit is no longer working, peaks have been lost, or
spectrum is unknown.
5
Pressure
Not within
operating range
Occurs when pressure is outside of the operating
range.
6
HD Space
Limited hard drive
space
Occurs when the internal hard drive has < 10% of
space left. Delete unnecessary data files.
7
Mirror Health
(A/B)
Mirrors have
declined in
reflectivity
Occurs when the ringdown time has degraded by
> 20% of the factory value. Mirror cleaning is
required.
8
Linelock (A/B)
Peak is outside
control range
Occurs when linelock control voltage is no longer
able to control.
9
Signal Power
(A/B)
Signal power has
degraded
Occurs when laser signal power has degraded by
> 20% of the factory value.
10
Maintenance
Maintenance
needed now
Occurs when the analyzer requires maintenance
(every 381 days).
11
CROSS OVER
12
Data Health
(A/B)
Fit is not optimal
The laser fitting condition is not optimal. Occurs
when residuals of fit go above normal operational
values.
13
Pressure
Noisy
Occurs when the specified operational pressure is
not optimal.
14
HD Space
Low space
Occurs when the internal hard drive has < 20%
space left.
Delete unnecessary data files.
15
Mirror Health
(A/B)
Mirrors have
declined in
reflectivity
Occurs when the ringdown time has degraded by
> 10% of the factory value.
16
Linelock (A/B)
Peak is drifting
Occurs when linelock control voltage is
approaching control range limit.
17
Signal Power
(A/B)
Signal power is
degrading
Occurs when laser signal power has degraded by
> 10% of the factory value.
18
Maintenance
Maintenance
needed soon
Analyzer maintenance will be needed soon (every
360 days).
