ABB TRIO-20.0-TL-OUTD-S-US-480

T010CC4
- 61 -
4 - Operations
Parameter Denition Default Value Adjustable Ranges
SET F<< Indicates the value of the absolute under frequency set
point below which the inverter disconnects from the grid
57.0 Hz 59.8 Hz to 55.0 Hz
SET U> Indicates the value of the intermediate over voltage set
point beyond which the inverter disconnects from grid
[110% of Nominal V
L-N
]
110% of
Nominal V
L-N
(110% x V
L-N
) to
(115% x V
L-N
)
SET U>
(10 min)
Inverter disconnects from grid after 10 minutes in case
the average grid voltage overcomes threshold value
(110% x V
L-N
)
110% of
Nominal V
L-N
(110% x V
L-N
) to
(115% x V
L-N
)
SET U< Indicates the value of the intermediate under voltage set
point below which the inverter disconnects from grid
[88% of Nominal V
L-N
]
88% of
Nominal V
L-N
(50% x V
L-N
) to
(88% x V
L-N
)
SET F> Indicates the value of the intermediate over frequency
set point beyond which the inverter disconnects from
grid
60.5 Hz 60.2 Hz to
65.0 Hz
SET F< Indicates the value of the intermediate under frequency
set point below which the inverter disconnects from grid
59.3 Hz 59.8 Hz to
55 Hz
SET U Conn> Indicates the value of the intermediate over voltage (line
to neutral) set point to allow the inverter to connect to the
grid for the rst time
110% of
Nominal V
L-N
(110% x V
L-N
) to
(115% x V
L-N
)
SET U Conn< Indicates the value of the intermediate under voltage
(line to neutral) set point to allow the inverter to connect
to the grid for the rst time
88% of
Nominal V
L-N
(50% x V
L-N
) to
(88% x V
L-N
)
SET F Conn> Indicates the value of the intermediate over frequency
set point to allow the inverter to connect to grid rst time
60.5 Hz 60.2 Hz to
63.0 Hz
SET F Conn< Indicates the value of the intermediate under frequency
set point to allow inverter to connect to the grid rst time
59.3 Hz 59.8 Hz to
57 Hz
SET TIME
U>>
Indicates the value of the countdown timer associated
with the absolute over voltage setpoint U>>
0.16 sec 160 msec to 65.5
sec
SET TIME
U<<
Indicates the value of the countdown timer associated
with the absolute under voltage setpoint U<<
0.16 sec 160 msec to 65.5
sec
SET TIME F>> Indicates the value of the countdown timer associated
with the absolute over frequency setpoint F>>
0.16 sec 160 msec to
327.67 sec
SET TIME F<< Indicates the value of the countdown timer associated
with the absolute under frequency setpoint F<<
0.16 sec 160 msec to
327.67 sec
SET TIME U> Indicates the value of the countdown timer associated
with the intermediate over voltage setpoint U>
1 sec 160 msec to
65.5 sec
SET TIME U< Indicates the value of the countdown timer associated
with the intermediate under voltage setpoint U<
2 sec 160 msec to
65.5 sec
SET TIME F> Indicates the value of the countdown timer associated
with the intermediate over frequency setpoint F>
0.16 sec 160 msec to
327.67 sec
SET TIME F< Indicates the value of the countdown timer associated
with the intermediate under frequency setpoint F<
0.16 sec 160 msec to
327.67 sec
