Abov MC96F6432S Series User Manual

102
MC96F6432S
ABOV Semiconductor Co., Ltd.
11.2.4 Basic Interval Timer Register Description
The basicinterval timer register consists of basic interval timer counter register (BITCNT) and basic interval timer
control register (BITCR). If BCLR bit is set to ‘1’, BITCNT becomes ‘0’ and then counts up. After 1 machine cycle,
BCLR bit is cleared to ‘0’ automatically.
11.2.5 Register Description for Basic Interval Timer
BITCNT (Basic Interval Timer Counter Register): 8CH
7
6
5
4
3
2
1
0
BITCNT7
BITCNT6
BITCNT5
BITCNT4
BITCNT3
BITCNT2
BITCNT1
BITCNT0
R
R
R
R
R
R
R
R
Initial value: 00H
BITCNT[7:0]
BIT Counter
BITCR (Basic Interval Timer Control Register): 8BH
7
6
5
4
3
2
1
0
BITIFR
BITCK1
BITCK0
–
BCLR
BCK2
BCK1
BCK0
R/W
R/W
R/W
–
R/W
R/W
R/W
R/W
Initial value: 01H
BITIFR
When BIT Interrupt occurs, this bit becomes ‘1’. For clearing bit, write ‘0’ to this bit or
auto clear by INT_ACK signal. Writing “1” has no effect.
0
BIT interrupt no generation
1
BIT interrupt generation
BITCK[1:0]
Select BIT clock source
BITCK1
BITCK0
Description
0
0
fx/4096
0
1
fx/1024
1
0
fx/128
1
1
fx/16
BCLR
If this bit is written to ‘1’, BIT Counter is cleared to ‘0’
0
Free Running
1
Clear Counter
BCK[2:0]
Select BIT overflow period
BCK2
BCK1
BCK0
Description
0
0
0
Bit 0 overflow (BIT Clock * 2)
0
0
1
Bit 1 overflow (BIT Clock * 4) (default)
0
1
0
Bit 2 overflow (BIT Clock * 8)
0
1
1
Bit 3 overflow (BIT Clock * 16)
1
0
0
Bit 4 overflow (BIT Clock * 32)
1
0
1
Bit 5 overflow (BIT Clock * 64)
1
1
0
Bit 6 overflow (BIT Clock * 128)
1
1
1
Bit 7 overflow (BIT Clock * 256)
