Abov MC96F6432S Series User Manual

235
MC96F6432S
ABOV Semiconductor Co., Ltd.
12.6 Register Map
Name
Address
Direction
Default
Description
PCON
87H
R/W
00H
Power Control Register
Table 12.2 Power Down Operation Register Map
12.7 Power Down Operation Register Description
The power down operation register consists of the power control register (PCON).
12.8 Register Description for Power Down Operation
PCON (Power Control Register): 87H
7
6
5
4
3
2
1
0
PCON7
–
–
–
PCON3
PCON2
PCON1
PCON0
R/W
–
–
–
R/W
R/W
R/W
R/W
Initial value: 00H
PCON[7:0]
Power Control
01H
IDLE mode enable
03H
STOP mode enable
Other Values
Normal operation
NOTE)
1. To enter IDLE mode, PCON must be set to ‘01H’.
2. To enter STOP mode, PCON must be set to ‘03H’.
3. The PCON register is automatically cleared by a release signal in STOP/IDLE mode.
4. Three or more NOP instructions must immediately follow the instruction that make the device enter
STOP/IDLE mode. Refer to the following examples.
Ex1) MOV PCON, #01H ; IDLE mode Ex2) MOV PCON, #03H ; STOP mode
NOP NOP
NOP NOP
NOP NOP
• •
• •
• •
