8.4 SFR Map
8.4.1 SFR Map Summary
00H/8H
(1)
01H/9H
02H/0AH
03H/0BH
04H/0CH
05H/0DH
06H/0EH
07H/0FH
0F8H
IP1
–
FSADRH
FSADRM
FSADRL
FIDR
FMCR
P5FSR
0F0H
B
USI1ST1
USI1ST2
USI1BD
USI1SDHR
USI1DR
USI1SCLR
USI1SCHR
0E8H
RSTFR
USI1CR1
USI1CR2
USI1CR3
USI1CR4
USI1SAR
P3FSR
P4FSR
0E0H
ACC
USI0ST1
USI0ST2
USI0BD
USI0SDHR
USI0DR
USI0SCLR
USI0SCHR
0D8H
LVRCR
USI0CR1
USI0CR2
USI0CR3
USI0CR4
USI0SAR
P0DB
P15DB
0D0H
PSW
P5IO
P0FSRL
P0FSRH
P1FSRL
P1FSRH
P2FSRL
P2FSRH
0C8H
OSCCR
P4IO
–
–
–
–
–
–
0C0H
EIFLAG0
P3IO
T2CRL
T2CRH
T2ADRL
T2ADRH
T2BDRL
T2BDRH
0B8H
IP
P2IO
T1CRL
T1CRH
T1ADRL
T1ADRH
T1BDRL
T1BDRH
0B0H
P5
P1IO
T0CR
T0CNT
T0DR/
T0CDR
SPICR
SPIDR
SPISR
0A8H
IE
IE1
IE2
IE3
P0PU
P1PU
P2PU
P3PU
0A0H
P4
P0IO
EO
P4PU
EIPOL0L
EIPOL0H
EIFLAG1
EIPOL1
98H
P3
LCDCRL
LCDCRH
LCDCCR
ADCCRH
ADCCRH
ADCDRL
ADCDRH
90H
P2
P0OD
P1OD
P2OD
P4OD
P5PU
WTCR
BUZCR
88H
P1
WTDR/
WTCNT
SCCR
BITCR
BITCNT
WDTCR
WDTDR/
WDTCNT
BUZDR
80H
P0
SP
DPL
DPH
DPL1
DPH1
LVICR
PCON
Table 8.1 SFR Map Summary
NOTE)
1. 00H/8H, These registers are bit-addressable.
2. Do not use the “direct bit test and branch” instruction on P0, P1, P2, P3, P4, P5 and EIFLAG0 registers.
More detail information is at chapter 17.2 Instructions on how to use the input port.
Example) Avoid direct input port bit test and branch condition as below
if(P00) → if(P0 & 0x01)
-
Reserved
M8051 compatible
