MC96F6432S
ABOV Semiconductor Co., Ltd.
7.3 A/D Converter Characteristics
(T
A
=-40°C ~ +85°C, VDD=1.8V ~ 5.5V, VSS=0V)
Parameter
Symbol
Conditions
MIN
TYP
MAX
Unit
Resolution
–
–
–-
12
–
bit
Integral Linear Error
ILE
AVREF= 2.7V – 5.5V
fx= 8MHz
–
–
±6
LSB
Differential Linearity Error
DLE
–
–
±1
Zero Offset Error
ZOE
–
–
±5
Full Scale Error
FSE
–
–
±5
Conversion Time
t
CON
12-bit resolution, 8MHz
20
–
–
us
Analog Input Voltage
V
AN
–
VSS
–
AVREF
V
Analog Reference Voltage
AVREF
*Note 3
1.8
–
VDD
Analog Input Leakage Current
I
AN
AVREF=5.12V
–
–
2
uA
ADC Operating Current
I
ADC
Enable
VDD=5.12V
–
1
2
mA
Disable
–
–
0.1
uA
Table 7.3 A/D Converter Characteristics
NOTE)
1. Zero offset error is the difference between 000000000000 and the converted output for zero input
voltage (VSS).
2. Full scale error is the difference between 111111111111 and the converted output for full-scale input
voltage (AVREF).
3. When AVREF is lower than 2.7V, the ADC resolution is worse.
7.4 Power-On Reset Characteristics
(T
A
=-40°C ~ +85°C, VDD=1.8V ~ 5.5V, VSS=0V)
Parameter
Symbol
Conditions
MIN
TYP
MAX
Unit
RESET Release Level
V
POR
–
–
1.4
–
V
VDD Voltage Rising Time
t
R
–
0.05
–
30.0
V/ms
POR Current
I
POR
–
–
0.2
–
uA
Table 7.4 Power-on Reset Characteristics
