11.13.3 LCD Signal Waveform
1 Frame
VDD
VSS
0 1
COM1
SEG1
COM0-SEG0
COM0
VSS
VLC0
VLC2(VLC1, VLC3)
COM0
COM1
SEG0
SEG1
SEG3
0
1
SEG2
SEG0
VSS
VSS
+VLC0
+VLC2(VLC1, VLC3)
-VLC2(VLC1, VLC3)
-VLC0
VSS
VSS
VLC0
VLC2(VLC1, VLC3)
VLC0
VLC2(VLC1, VLC3)
VLC0
VLC2(VLC1, VLC3)
Figure 11.75 LCD Signal Waveforms (1/2Duty, 1/2Bias)
