Abov MC96F6432S Series User Manual

10
MC96F6432S
ABOV Semiconductor Co., Ltd.
2 Block diagram
XRAM
768B
IRAM
256B
Flash
32KB
ISP
In-system programming
Power control
Power on reset
Low voltage reset
Low voltage indicator
Power down mode
Clock generator
16MHz, Internal RC OSC
12MHz, Crystal OSC
32.768kHz, Crystal OSC
LCD driver
21 segments
Buzzer
1 channel, 8-bit
UART
2 channels, 8-bit
SPI
3 channels, 8-bit
I2C
2 channels, 8-bit
CORE
M8051
General purpose I/O
9 ports normal I/O
33 ports LCD shared I/O
Watchdog timer
1 channel, 8-bit
5kHz, internal RC OSC
Basic interval timer
1 channel, 8-bit
Timer / Counter
1 channel, 8-bit
2 channels, 16-bit
2 channels, 8-bit
or 1 channel, 16-bit
ADC
16 Input channels, 12-bit
PWM
6 channels
Figure 2.1 Block diagram of MC96F6432S
