15.1.5 Register Description for Flash
FSADRH (Flash Sector Address High Register): FAH
7
6
5
4
3
2
1
0
–
–
–
–
FSADRH3
FSADRH 2
FSADRH1
FSADRH0
–
–
–
–
R/W
R/W
R/W
R/W
Initial value: 00H
FSADRH[3:0]
Flash Sector Address High
FSADRM (Flash Sector Address Middle Register): FBH
7
6
5
4
3
2
1
0
FSADRM7
FSADRM6
FSADRM5
FSADRM4
FSADRM3
FSADRM2
FSADRM1
FSADRM0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
FSADRM[7:0]
Flash Sector Address Middle
FSADRL (Flash Sector Address Low Register): FCH
7
6
5
4
3
2
1
0
FSADRL7
FSADRL6
FSADRL5
FSADRL4
FSADRL3
FSADRL2
FSADRL1
FSADRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
FSADRL[7:0]
Flash Sector Address Low
FIDR (Flash Identification Register): FDH
7
6
5
4
3
2
1
0
FIDR7
FIDR6
FIDR5
FIDR4
FIDR3
FIDR2
FIDR1
FIDR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
FIDR[7:0]
Flash Identification
Others
No identification value
10100101
Identification value for a flash mode
(These bits are automatically cleared to logic ‘00H’ immediately after one time
operation)
