Abov MC96F6432S Series User Manual

125
MC96F6432S
ABOV Semiconductor Co., Ltd.
11.6.7 Timer/Counter 1 Register Description
The timer/counter 1 register consists of timer 1 Adata high register (T1ADRH), timer 1 Adata low register (T1ADRL),
timer 1 Bdata high register (T1BDRH), timer 1 Bdata low register (T1BDRL), timer 1controlHigh register (T1CRH) and
timer 1controllow register (T1CRL).
11.6.8 Register Description for Timer/Counter 1
T1ADRH (Timer 1 A data High Register): BDH
7
6
5
4
3
2
1
0
T1ADRH7
T1ADRH6
T1ADRH5
T1ADRH4
T1ADRH3
T1ADRH2
T1ADRH1
T1ADRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T1ADRH[7:0]
T1 A Data High Byte
T1ADRL (Timer 1 A Data Low Register): BCH
7
6
5
4
3
2
1
0
T1ADRL7
T1ADRL6
T1ADRL5
T1ADRL4
T1ADRL3
T1ADRL2
T1ADRL1
T1ADRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T1ADRL[7:0]
T1 A Data Low Byte
NOTE)
1. Do not write “0000H” in the T1ADRH/T1ADRL register when PPG
mode
T1BDRH (Timer 1 B Data High Register): BFH
7
6
5
4
3
2
1
0
T1BDRH7
T1BDRH6
T1BDRH5
T1BDRH4
T1BDRH3
T1BDRH2
T1BDRH1
T1BDRH0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T1BDRH[7:0]
T1 B Data High Byte
T1BDRL (Timer 1 B Data Low Register): BEH
7
6
5
4
3
2
1
0
T1BDRL7
T1BDRL6
T1BDRL5
T1BDRL4
T1BDRL3
T1BDRL2
T1BDRL1
T1BDRL0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: FFH
T1BDRL[7:0]
T1 B Data Low Byte
