Abov MC96F6432S Series User Manual

173
MC96F6432S
ABOV Semiconductor Co., Ltd.
11.10.6 Register Map
Name
Address
Direction
Default
Description
SPISR
B7H
R/W
00H
SPI 2 Status Register
SPIDR
B6H
R/W
00H
SPI 2 Data Register
SPICR
B5H
R/W
00H
SPI 2 Control Register
Table 11.17 SPI 2Register Map
11.10.7 SPI 2 Register Description
The SPI 2 register consists of SPI 2 control register (SPICR), SPI 2 status register (SPISR) and SPI 2 data register
(SPIDR)
11.10.8 Register Description for SPI 2
SPIDR (SPI 2 Data Register): B6H
7
6
5
4
3
2
1
0
SPIDR7
SPIDR6
SPIDR5
SPIDR4
SPIDR3
SPIDR2
SPIDR1
SPIDR0
R/W
R/W
R/W
R/W
R/W
R/W
R/W
R/W
Initial value: 00H
SPIDR [7:0]
SPI 2 Data
When it is written a byte to this data register, the SPI 2 will start
an operation.
